TLV COSPECT

Pressure reducing valve with built-in separator and steam trap

COSPECT is technologically advanced pressure reducing valve combined with condensate separator and steam trap. Built-in strainer, Super Cyclonical Effects Separator (SCE) and Free Float steam trap help prevent scale, rust and condensate from entering the pressure reducing valve (PRV) or reaching the important interior parts. Self-aligning shock-absorbing spherical piston and advanced pilot regulator designs maintain secondary steam pressure accuracy, even during adverse process conditions. It has internal pressure sensing channel and also possibility to use external sensing line. Pilot valve is protected by fine mesh screen. Sizes DN 65 and larger have a silencer for noise reduction.

Have any questions about the product?
Valve Operation Principle

Pilot operated control valve with built-in separator and steam trap

Size

DN 15 – 100

Pressure

PN 16-40, ANSI 150-300

Material

Ductile Iron, Stainless Steel

Operating Pressure

Maximum Operating Pressure: 21 barg

Operating Temperature

Maximum Operating Temperature: 220 °C

Minimum Adjustable Flow Rate

5% of rated flow rate

Connection

Flange

Manufacturers

TLV

Country of Origin

Japan

Industry Sectors

Biotechnology, Chemical, Boiler and Power Plants, CHP, Breweries, Building materials, Dairies, Distilleries, Food and Beverage, Hospitals, Mining, Metallurgy, Oil&Gas, Refineries, Pharma and cosmetics, Pulp&Paper, Textile, Laundries, Timber, Pelletizing, Tire, rubber and plastic

Applications

Condensate, Superheated water, Steam, Superheated steam, Water and Wastewater
